The 51.2V 5.12kWh Wall Mounted Home Energy Storage Battery is an integrated residential energy storage solution for household power needs. Manufactured by Huda New Energy, this wall-mounted battery adopts compact structure for simple indoor installation. It can connect with solar panels, utility grid and generators to realize solar self-consumption, peak shaving, emergency backup power and EV charging.
The 5.12kWh Home Energy Storage Battery is a compact wall-mounted LiFePO4 battery, built for household solar systems. This 5.12kWh Home Energy Storage Battery delivers reliable backup power during grid outages and optimizes self-consumption of solar power.
Wall-mounted compact design, space-saving and easy installation High safety LiFePO4 battery cells, 6000+ cycles @80% DOD for long service life All-in-one smart energy management, compatible with solar, grid and generator Supports multiple home scenarios, including backup power and EV charging Built-in intelligent BMS protection to guarantee household power safety
This wall-mounted home battery is widely used for residential solar energy storage. It helps homeowners store excess solar power generated in daytime for later use. During grid outages, it supplies emergency backup power to keep essential appliances running. It also supports peak shaving to cut electricity bills and clean EV charging with stored solar energy.
Huda supports OEM and ODM service to meet customized requirements for home energy storage projects.
Our 5.12kWh Home Energy Storage Battery adopts LiFePO4 cells and intelligent BMS protection to ensure safe and stable power supply for your home solar system.
| Parameter Item | H096-5kWh class | H096-10kWh class | H096-15kWh class |
|---|---|---|---|
| Model | H096-5kWh class | H096-10kWh class | H096-15kWh class |
| Battery capacity | 100Ah/51.2V (5.12kWh) | 200Ah/51.2V (10.24kWh) | 280Ah/51.2V (14.33kWh) |
| Size (whl) | L460mmW145mmH515mm | L460mmW245mmH620mm | L460mmW245mmH760mm |
| Weight | 45 kg | 95 kg | 120 kg |
| Battery type | LiFePO₄ | LiFePO₄ | LiFePO₄ |
| Battery voltage range | 40-58V | 40-58V | 40-58V |
| Communication mode | Support WIFI bluetooth connection with mobile APP | Support WIFI bluetooth connection with mobile APP | Support WIFI bluetooth connection with mobile APP |
| Communicate | RS485/CAN | RS485/CAN | RS485/CAN |
| Battery cycle life | After 3000 cycles, the remaining capacity is still more than 80% | After 3000 cycles, the remaining capacity is still more than 80% | After 3000 cycles, the remaining capacity is still more than 80% |
| System protection | Over temperature protector/Over voltage protection/Over current protection/Over charge protection/Over discharge protection/Load short circuit protection/Over load protection. | Over temperature protector/Over voltage protection/Over current protection/Over charge protection/Over discharge protection/Load short circuit protection/Over load protection. | Over temperature protector/Over voltage protection/Over current protection/Over charge protection/Over discharge protection/Load short circuit protection/Over load protection. |
| Discharge temperature | -20℃~50℃ (The recommended ambient temperature is 20℃ to 30℃.) | -20℃~50℃ (The recommended ambient temperature is 20℃ to 30℃.) | -20℃~50℃ (The recommended ambient temperature is 20℃ to 30℃.) |
| Charging temperature | -5℃~50℃ (The recommended ambient temperature is 20℃ to 30℃.) | -5℃~50℃ (The recommended ambient temperature is 20℃ to 30℃.) | -5℃~50℃ (The recommended ambient temperature is 20℃ to 30℃.) |
| Storage temperature | The recommended ambient temperature is 0℃ to 45℃ | The recommended ambient temperature is 0℃ to 45℃ | The recommended ambient temperature is 0℃ to 45℃ |
| User Interface | LCD | LCD | LCD |
| Protection level | IP20 | IP20 | IP20 |
| Installation mode | Wall-mounted | Floor-standing | Floor-standing |
| Certification standards | CE FCC ROHS | CE FCC ROHS | CE FCC ROHS |
Huda New Energy is a professional manufacturer and exporter of home energy storage batteries. We focus on developing high-quality residential energy storage products. Our products have passed relative certification for global market. We provide full after-sales support, technical guidance and long product warranty for all our home storage projects.
If you need higher capacity, check our 10kWh home energy storage battery for larger household power backup.
Q1: What is the cycle life of this 51.2V 5.12kWh wall mounted home battery?
A1: It adopts LiFePO4 cells, supporting over 6000 cycles at 80% DOD with long service life.
Q2: Can this battery work with solar panels for home solar storage?
A2: Yes. It is compatible with solar systems, grid and generators to realize solar self-consumption.
Q3: Does this wall battery have built-in BMS protection?
A3: Yes, intelligent BMS is integrated to protect the battery from overcharge, over-discharge and short circuit.
Q4: Can you provide OEM & ODM customization service?
A4: Yes, Huda New Energy supports OEM and ODM services to meet your project demands.
Q5: What after-sales support can I get from Huda New Energy?
A5: We offer technical guidance, complete after-sales service and long-term product warranty.
