| Model | H098-193kWh | ||
| Size (LWH) | 1340mm1100mm2280mm | Battery recharging method | DC national standard DC national standard charging gun |
| Weight | 1600kg | AC：380Vac(3P+N+PE) | |
| Battery voltage | 614.4V | Output power | 180kW |
| Battery voltage range | 480V-700.8V | Output voltage | DC200-1000V |
| Rated energy | 193kWh | Charging current | 0-250A |
| Rated input power | 60kW | Charging gun standard | National standard (customizable) |
| Rated output power | 120kW | Charging gun cable length | 7m |
| Rated grid voltage | 380V | Communication method | 4G |
| Grid voltage range | 323V~418V | Operating temperature range | -30°C~+50°C |
| Grid frequency range | 45Hz-55Hz | Maximum operating altitude | 3000m |
| Protection class | IP55 | Certification standards | GBIT 36276,GBT 34131,GBIT 34120,GBT 34133 |
| Temperature control method | intelligent liquid cooling | Communication interface | LAN/CAN/485 |
